Ob chav Planetary Mixer Polymer Epoxy Resin
Thaum lub sij hawm khiav ntawm ob lub ntiaj teb lub tshuab nqus tsev fais fab tov khoom, Ob qho tib si sib xyaw paddles khiav hauv kev sib tw nrog cov txheej txheem kev sib hloov, kev kub ceev rotating ntawm nws tus kheej axis tib lub sij hawm ntawm orbital kiv puag ncig.Muaj scraper khiav ua ke nrog paddles 'orbital kiv puag ncig hauv lub tank sib tov, uas txav cov khoom mus rau paddles los ntawm lub tank phab ntsa, kom khaws cov sib txawv shearing,
Hauj lwm lawm
Kev sib xyaw ua haujlwm ntawm ob lub ntiaj teb sib tov yog 10 npaug tshaj li cov khoom sib xyaw
Tshwj xeeb twist paddle tsim thiab advanced mixing txoj cai.
Cov twist sib tov paddles thiab kev kub ceev dispersion shafts revolve thiab tig tib lub sijhawm. Cov twist hniav ua rau cov khoom nyob rau hauv lub chim ntws nce thiab nqis. Lub siab ceev dispersion phaj txuas ntxiv shear thiab tawg cov khoom.
Ib tus pab zoo rau kev sib tov - Phab ntsa Scraper
Lub scraper tuaj yeem tshem tawm cov khoom viscous ntawm sab hauv phab ntsa ntawm lub thoob kom paub tseeb tias tsis muaj qhov sib xyaw tuag ntawm cov khoom hauv lub thoob thiab txhua yam khoom tuaj yeem koom nrog hauv kev sib xyaw kom zoo.
Multi-functional Tank
Lub tshuab nqus tsev vacuum, uas lub tshuab nqus tsev tsis thauj khoom khaws cia saum toj no -0.095 hauv 24 teev;
Cua sov & Txias lub tsho, uas qhov ntsuas kub tuaj yeem hloov kho raws li cov khoom siv;
Hloov lub thoob yog nrog kev ua tiav thiab kev tu yooj yim.
Tshwj xeeb twist paddle tsim thiab advanced mixing txoj cai.
Cov twist sib tov paddles thiab kev kub ceev dispersion shafts revolve thiab tig tib lub sijhawm. Cov twist hniav ua rau cov khoom nyob rau hauv lub chim ntws nce thiab nqis. Lub siab ceev dispersion phaj txuas ntxiv shear thiab tawg cov khoom.
Ib tus pab zoo rau kev sib tov - Phab ntsa Scraper
Lub scraper tuaj yeem tshem tawm cov khoom viscous ntawm sab hauv phab ntsa ntawm lub thoob kom paub tseeb tias tsis muaj qhov sib xyaw tuag ntawm cov khoom hauv lub thoob thiab txhua yam khoom tuaj yeem koom nrog hauv kev sib xyaw kom zoo.
Multi-functional Tank
Lub tshuab nqus tsev vacuum, uas lub tshuab nqus tsev tsis thauj khoom khaws cia saum toj no -0.095 hauv 24 teev;
Cua sov & Txias lub tsho, uas qhov ntsuas kub tuaj yeem hloov kho raws li cov khoom siv;
Hloov lub thoob yog nrog kev ua tiav thiab kev tu yooj yim.
Specification
|
Yam khoom Model
|
5L
|
30L
|
60L
|
100L
|
200L
|
|
Tank ua haujlwm Muaj peev xwm / L
|
5L
|
30L
|
60L
|
100L
|
200L
|
|
Tank Design Loj / L
|
7.4L
|
44L
|
88L
|
149L
|
287L
|
|
Tank Loj / mm
|
250*150
|
400*350
|
500*450
|
650*450
|
750*650
|
|
Revolution Tsav / Kw
|
1.5
|
3
|
7.5
|
11
|
22
|
|
Revolution Ceev / rpm
|
0.-51
|
0-43
|
0-36
|
0-30
|
0-28
|
|
Mix Ceev/rpm
|
0-104
|
0-84
|
0-53
|
0-46
|
0-39
|
|
Disperse Motom/Kw
|
1.5
|
5.5
|
11
|
15
|
30
|
|
Disperse Ceev / rpm
|
0-9500
|
0-5500
|
0-4500
|
0-3700
|
0-2800
|
|
Disperse phaj linear Velocity(m/s)
|
|
0-23
|
|||
|
Qhov hnyav / Kg
|
420
|
980
|
1700
|
2700
|
4200
|
|
Kev ntsuas / hli (L * W * H)
|
1250*770*1500
|
1700*950*1900
|
1950*1200*2150
|
2300*1300*2400
|
2500*1400*3000
|
Cov khoom zoo sib xws
Daim ntawv thov
Dab tsi yog Daim Ntawv Thov Ntawm Ob Lub Planetary Mixer?
Ob chav planetary tov khoom tau txais cov cuab yeej siv siab heev, uas yog siv dav hauv kev sib faib nruab nrab lossis siab viscosity kua-kua / khoom-khoom / kua-khoom khoom, xws li cov nplaum, sealant, silicone roj hmab, iav kua nplaum, solder paste, quartz xuab zeb, roj teeb muab tshuaj txhuam, hluav taws xob slurry, lithium roj teeb slurry, polyurethane, txheej, pigment, dyestuff, hluavtaws resin roj hmab, tshuaj pleev thiab lwm yam rau electronics, tshuaj, kev tsim kho thiab kev ua liaj ua teb industries.which lub viscosity yog app. los ntawm 5000cp mus rau 1000000cp.
Tuam txhab Profile
Qinhuangdao Yushun Intelligent Technology Co., Ltd tau sau npe nyob rau lub Rau Hli, 2011, peb lub Hoobkas tsim nyob rau hauv 1995, nws muaj txog 27 xyoo kev ua haujlwm, Yushun yog ib ceg tshiab ntawm peb pawg. Nws yog ib tug reasch thiab kev loj hlob, ntau lawm thiab muag khoom lag luam uas nrog abounding ntau lawm experie. Peb xyuas kom meej muab cov khoom zoo tshaj plaws. Peb yog cov chaw tsim khoom ntawm lithium roj teeb automation equipments xws li ob chav planetary tov khoom, dual-channel roj teeb slurry sib nqus lim, siab ceev homogenizer, slurry hloov tank, lithium-ion roj teeb tsis siv neeg pub noj thiab mills. Peb muaj lwm lub tuam txhab Qinhuangdao Pengyi Chem-kev lag luam Machinery Co., Ltd. Pengyi muaj 23 xyoo kev hauv kev lag luam tshuaj. Peb lub tshuab tau muab kev pabcuam rau cov neeg siv khoom los ntawm Asmeskas, Russia, Ltalis, Is Nrias teb, Asutralia, Egypt, Sri Lanka, Ukraine, Thaib, Braliz, Malaysia, Nyab Laj thiab lwm yam. Peb cov khoom zoo thiab kev pabcuam tau txais kev pom zoo los ntawm cov neeg siv khoom sab hauv thiab thoob ntiaj teb.
Packing & Delivery
1. Ntim nrog lub thawv ntoo, sab hauv nrog cov khoom tiv thaiv kev sib tsoo los tiv thaiv lub tshuab lossis raws li cov neeg siv khoom xav tau.
2. Shipping los ntawm hiav txwv, los ntawm huab cua, los ntawm lan tsheb thauj mus los, nthuav qhia raws li tus neeg yuav tsum tau muaj.
2. Shipping los ntawm hiav txwv, los ntawm huab cua, los ntawm lan tsheb thauj mus los, nthuav qhia raws li tus neeg yuav tsum tau muaj.
